New Power ND6
Pris ekskl. moms
Ring for pris
8
Favorit
Del
Gem søgningUdskriv
INFO
Produktgruppe
Bulldozer på larvebånd
Mærke / model
New Power ND6
Årgang
2019
Driftstimer
5 h
Ekstra valgmuligheder
Ny
Maskinplacering
jining
Land
Kina
Generel klasse
1
2
3
4
5
Mascus ID
59C2CAED
DETALJER
Seneste inspektion
yes
Bruttovægt
19500 kg
Klinge type
Lige klinge
Understel
Sporbundet
Kabinetype
Lukket kabine
Udstødningsklasse
Trin II
Motor
Shangchai SC9DK190G3
Motorydelse
147 kW (200 hk)
Båndbredde
560 mm
Transportmål (LxBxH)
4175000 x 2440000 x 3400000 mm
Original farve
Yellow
Tilstandsoplysninger/Garanti
yes
Produktionsland
Kina
Forsendelsesbetingelser
FOB, CFR, CIF, EXW
Tilbehør
ROPS
Udstyr
Klimaanlæg
Supplerende hydraulik
Multi shank ripper
Øvrige oplysninger
The most fuel efficient dozer
Hydrostatic travel drive with electronic control
Shangchai engine with CATERPILLAR pedigree (optional Cummins) were developed for the most demanding conditions of use. Their low rated speed ensures high operational reliability and a long lifetime.
Model ND6
Engine model SDEC SC9DK190G3
Rated power(kw/rpm) 147/1700 kw/rpm
Displacement(L) 8.8
Max.torque(N.m/rpm) 920/1400
Operating weight(Kg) 19575
Dimension(no ripper)(mm) 4175*2440*3400
Min ground clearance(mm) 390
Ground pressure(MPa) 0.65 kg/cm2
Track shoe width(mm) 560
Track gauge(mm) 1880
Dozing capacity( m³) 5.65
Blade width(mm) 3160
Blade height(mm) 1410
Max drop below ground(mm) 473
Pitch(mm) 203
Quantity of track link 39
Max pressure(MPa) 26MPa
Grade ability(°) 30
Forward(km/h) 4.8/7.8/11
Reverse(km/h) 4.8/7.8/11Materials and specifications are subject to change without notice
Jining Haoduo Import and export co., Ltd.
Second floor, First section, No.2 building,Jining Lantian Boiler 272000 Jining 济宁 Shandong 山东 Kina
