Sunward SWE 60

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours:24 hours, holidays and Sundays Contact: Lily Whatsapp: +86 13696501072 Mobile:+86 17756597429 Wechat:17756597429 Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.

Sunward Intelligent SWE60E Excavator Parameter Configuration specification Power: Traditional power Manufacturer domestic Bucket backhoe Tonnage (tons) 6 The working weight of the whole machine (kg) is 6000 Bucket capacity (m³) 0.22 Boom length (mm) 3000 Stick length (mm) 1600 performance Rotation speed (rpm) 9.4 Travel speed (km/h) 4.07/2.43 Climbing ability (%) 35° Grounding specific pressure (Kpa) 34.5 Bucket digging force (kN) 47 Bucket digging force (kN) 31 Maximum traction (kN) 42.1 dynamical system Engine model YANMAR 4TNV94L-BVSUC Rated power (kw/rpm) 36.2/2100 Displacement (L) 3.054 Cooling method: Water cooling Working form: 4 cylinders, 4 strokes, water cooling Hydraulic system Main pump type: 2 variable piston pumps, 1 gear pump The maximum flow rate of the main pump (l/min) is 2×59+42 The main overflow set pressure (Mpa) is 2×24.5+21 Oil capacity Fuel tank (L) 113 Hydraulic Tank (L) 96 Body size Total length of transport (mm) 5875 Total width of transport (mm) 1900 Total height of transport (mm) 2615 Cab total height (mm) 2615 Boarding width (mm) 1900 Track grounding length (mm) 1965 Total track length (mm) 2495 Track shoe width (mm) 400 Total Track Width (mm) 1880 Track gauge (mm) 1480 Minimum ground clearance (mm) 320 Counterweight ground clearance (mm) 700 The minimum turning radius of the front working device (mm) is 2410 Rear end slewing radius (mm) 1600 Scope of work Maximum digging radius (mm) 6175 The maximum excavation radius of the stopping surface (mm) is 6030 Maximum digging depth (mm) 3730 Maximum digging height (mm) 5765 Maximum unloading height (mm) 4160 Maximum vertical digging depth (mm) 2800 Width × height (mm) of bulldozer plate 1900×340 Bulldozer lifting or pushing depth (mm) 445/340
