CAT 313

Pris ekskl. moms

Images8
CAT 313 Midi-gravemaskiner 7t - 12t
CAT 313 Midi-gravemaskiner 7t - 12t
CAT 313 Midi-gravemaskiner 7t - 12t
FavoriteFavorit
shareDel
Save searchGem søgning
Udskriv

INFO

Produktgruppe
Midi-gravemaskiner 7t - 12t
Mærke / model
CAT 313
Årgang
2022
Driftstimer
700 h
Land
Kina
Generel klasse
1
2
3
4
5
Mascus ID
007372FA

PRISSÆTNING

Vælg valuta

DETALJER

Antal tidligere ejere
1
Undervognens tilstand
good
Bruttovægt
13000 kg
Udstødningsklasse
Fase 5
Motorydelse
90 kW (122 hk)
Motormærke (eller motorproducent)
japan
Skovlkapacitet
0.65 m3
Båndbredde
600 mm
Transportmål (LxBxH)
761024902.83 m
Original farve
YELLOW
Rækkevidde
960 mm
Tilstandsoplysninger/Garanti
good
Produktionsland
Japan
Forsendelsesbetingelser
FOB, EXW
Certifikater
EPA, CE, ANSI, AS, CSA, EAC GOST, TRUA, JIS, TÜV, ASME
Tilbehør
All the auxiliary accessories can be provided for you. The above information is for reference only, and the specific details need to be confirmed with the factory.
Udstyr
Auto/hydraulisk hurtigkobling
Stik/Bom Slangebrudsventil
Slangebrudsventil på stik
GPS
Vis mere
Øvrige oplysninger
Here are the parameters of Caterpillar CAT313 excavator: - **General Parameters** - **Model**: CAT®313 GC - **Working Weight**: 12,400 kg - **Bucket Capacity**: 0.53 m³ (0.6 m³ is optional) - **Engine Parameters** - **Engine Model**: Cat C3.6 - **Rated Power - ISO 14396**: 74.4 kW - **Rated Power - ISO 9249**: 70.6 kW - **Rated Speed**: 2200 r/min - **Displacement**: 3.6 L - **Bore × Stroke**: 98 mm × 120 mm - **Emission Standard**: National IV - **Hydraulic System Parameters** - **Main System - Maximum Flow - Equipment**: 247 L/min - **Maximum Pressure - Equipment - Normal**: 35,000 kPa - **Maximum Pressure - Travel**: 35,000 kPa - **Maximum Pressure - Swing**: 26,000 kPa - **Swing System Parameters** - **Swing Speed**: 11.5 rpm - **Maximum Swing Torque**: 43 kN·m - **Dimensions and Working Ranges** - **Boom Reach**: 4.65 m - **Stick Reach**: 2.5 m - **Shipping Height**: 2780 mm (top of cab) - **Handrail Height**: 2820 mm - **Shipping Length**: 7630 mm - **Tail Swing Radius**: 2160 mm - **Counterweight Clearance**: 895 mm - **Ground Clearance**: 425 mm - **Track Length**: 3490 mm - **Distance between Center of Track Rollers**: 2780 mm - **Track Gauge**: 1990 mm - **Transport Width**: 2490 mm - **Maximum Digging Depth**: 5770 mm - **Maximum Reach at Ground Level**: 8210 mm - **Maximum Cutting Height**: 8530 mm - **Maximum Loading Height**: 6070 mm - **Minimum Loading Height**: 1980 mm - **Maximum Depth Cut for 2440 mm Level Bottom**: 5370 mm - **Maximum Vertical Wall Digging Depth**: 5040 mm - **Force Parameters** - **Bucket Digging Force - ISO**: 95.7 kN - **Stick Digging Force - ISO**: 68.2 kN - **Oil Capacity** - **Fuel Tank**: 237 L - **Hydraulic Tank**: 77 L - **Cooling System**: 11 L - **Engine Oil**: 11 L - **Final Drive**: 3 L per sideVis mere

Shanghai FanChi Machinery trading Co., LTD

hongmei Road 200000 Minhang Shanghai 上海 Kina
